This power supply is designed to be used when you need to power security cameras that demand higher power inputs. This unit can provide up to 30 amps of 12V DC power which is more than twice the power output of the average power supply.
If you are using long range infrared cameras that use 12V DC power, we highly recommend this power supply.
This power supply box is a 12V DC output, 30 AMP regulated. Each channel is individually fused using PTC auto reset fuses rated at 1.6 amps. This power distribution box can power up to 16 CCTV cameras, HD security cameras, or IP cameras.
The required power input is 110~120VAC. This power supply box can be wired using the 18/2 conductor cable from RG59 Siamese as well as pre-made security camera cables.
Powering multiple cameras could Not be easier! line of Professional CCTV Power Supplies give installers what they expect when it comes to power supplies quality and reliability
Every channel is protected with Auto-Reset PTC fuses which means these fuses will Not blow
This box can be mounted to any surface plugged into an AC outlet and up in seconds!
12VDC – 30amp supply current | Multiple outputs (32 channel) | 32 auto-reset PTC fuse protected output | Power on/off switch
DC regulated, over current and voltage protected | Individual LED indicator for each out put | Dimensions:25cm21.3cm9.5cm | Fuse Rating: 1.1A
